Termostufa a Legna Prity WD W24 D, 24.3kW
Wood-burning fireplace with provision for heating system and large combustion chamber. Sides with decorative metallic coating. The medium power model of the series.





- Stock: Disponibile
- Marchio: Prity
- SKU: 08.435.048
Risparmia il 5% con bonifico bancario.


Resi gratuiti
60 giorniVedi i dettagli
Pagamenti
Vedi i dettagli
Potrebbe anche essere necessario
Color: black graphite.
- Body in 2mm thick sheet steel.
- 3-4mm thick sheet steel plate.
- Water jacket for central heating system.
- The combustion chamber is equipped with a thermo-shock glass ceramic.
- Cast iron grill.
- It has a valve in the front to regulate the intensity of combustion.
- Manual control valve of the flue to control the draft of the flue itself.
Attention!
- Do not use without radiators and / or convectors installed. Burning wood in the stove prepared for an empty heating system will cause it to burst.
- Achieving the desired power depends on:
- By selecting the fuel with the necessary calorific values and humidity.
- Subsequent ignition and refueling / fueling.
- Primary and secondary air regulation.
- Adjustment of the draft of the flue.
- Effective air exchange, etc.
Recommendations
- We recommend that the central heating system be of the open type. If closed, it must be secured with a 1.5 bar pressure relief valve. All parts of the system must be protected from freezing. For forced circulation systems, it is recommended to install a UPS on the circulation pump.
- In the presence of copper elements in any part of the system, it must be protected from electrolysis by the addition of a magnesium anode or similar type of protection.
Caratteristiche | |
Peso (kg) | 160.0000 |
Stato di Produzione | Bulgaria |
Dimensioni Profondità (mm) | 550 |
Dimensioni Larghezza (mm) | 650 |
Dimensione Altezza (mm) | 930 |
Pressione di esercizio (bar) | 1 |
Certificazione | Eco Design |
Potenza termica nominale (kW) | 24.3 |
Superficie di riscaldamento approssimativa (m²) | 165 |
Classe di efficienza energetica | A |
Volume del mantello (L) | 31 |
Canna fumaria (mm) | 150 |
Potenza termica (kW) | 24.3 |
Efficienza (%) | 76.8 |
Capacità di riscaldamento approssimativa (m³) | 446 |
Potenza termica nominale del serbatoio d`acqua (kW) | 18.2 |
Consumo di carburante durante il periodo di riscaldamento | 7.9 kg/h |
Potenza di riscaldamento dell`ambiente (kW) | 6.1 |
Ingresso acqua fredda | 1" |
Uscita acqua calda | 1" |
Surriscaldamento protetto | No |
Contenitore di cenere e fuliggine | Si |
Tipo di riscaldamento | Hydro - Radiatore |
CO misurato al 13% di ossigeno alla potenza nominale (ridotta) | 1192.5 mg/Nm³ |
Emissioni (g/s) | 24,4 |
Rivestimento | Rivestimento decorativo |
Posizionamento | Centro |
Lunghezza massima dei tronchi di legna da ardere (mm) | 440 |
Dimensioni della camera di combustione (altezza, larghezza, profondità), mm | 300 x 510 x 450 |
Tipo di sistema raccomandato | Aperto |
Serranda fumi | Si |
